Downloading and Installing Siddhi Extensions¶ The Siddhi extensions supported for the WSO2 Integrator: SI are shipped with the product by default. If you need to install an additional extension or a different version of one, you can do so in two ways: Via the Extension Installer panel in WSO2 Integrator (recommended for development). Via the extension-installer script in the terminal (for production / headless setups). The installation status terminology is the same in both paths. Understanding installation status¶ Each Siddhi extension has one of the following installation statuses, reported by both the Extension Installer panel and the extension-installer CLI: Installation Status Description INSTALLED The extension is completely installed. The installation includes the JAR of the extension itself as well as all its dependencies (if any). NOT_INSTALLED The extension has not been installed. The JAR of the extension itself has not been installed. Dependencies (if any) may already be installed due to shared dependencies. PARTIALLY_INSTALLED The JAR of the extension itself has been installed, but one or more dependencies still need to be installed. When this status is displayed with an asterisk (PARTIALLY_INSTALLED (*)), there are one or more dependencies that need to be manually installed for the extension. To view the dependencies that need to be installed, check the installation status of that specific extension individually (see below). Restart Required The installation or uninstallation of the extension is staged but not yet active. Reload WSO2 Integrator (or restart the SI server, for terminal installs) to complete the operation. This status appears only in the Extension Installer panel — the terminal flow prompts you to restart the SI server explicitly. Status names appear in UPPERCASE_WITH_UNDERSCORES in the CLI and in Title Case in the Extension Installer panel. Installing extensions via WSO2 Integrator: SI¶ WSO2 Integrator includes an Extension Installer panel that lists all supported Siddhi extensions with their current installation status. You can install or uninstall extensions with a single click. Opening the Extension Installer panel¶ In WSO2 Integrator, open the command palette by pressing Ctrl + Shift + P (or Cmd + Shift + P on macOS), type SI: Extension Installer, and select the SI: Extension Installer option. The Extension Installer panel opens. To narrow down the list, enter all or part of an extension's name in the Search field at the top of the panel. Installing an extension¶ In the Extension Installer panel, locate the extension you want to install. Click Install for that extension, then confirm in the dialog box that appears. Reload WSO2 Integrator after the installation completes. The extension's status changes to Installed. Uninstalling an extension¶ In the Extension Installer panel, locate the extension you want to uninstall. Click UnInstall for that extension. If the extension you are uninstalling has shared dependencies with one or more other extensions, a warning appears. The names of the other extensions are in bold, and the dependencies each shares with the extension you are uninstalling are listed under the extension name. Note If you click Confirm, the other extensions that use the shared dependencies lose some of their dependencies. If you need to continue using those extensions, reinstall them after uninstallation. If there are no shared dependencies, click UnInstall in the confirmation dialog box. Reload WSO2 Integrator after the uninstallation completes. Manually installable dependencies¶ Some Siddhi extensions have dependencies that the Extension Installer cannot auto-download. These dependencies must be manually downloaded and installed before the extension is fully usable. When an extension has at least one such dependency, an information icon appears next to the extension's status in the Extension Installer panel: Click the icon to open a dialog box with details about each dependency. For each dependency, the dialog box provides: Instructions to download (and, where applicable, convert) the JAR of the dependency. Installation Location where the downloaded JAR (or converted OSGi bundle) needs to be placed. Each location maps to one of the following directories: Installation Location Directory bundle in runtime Place the OSGi bundle you downloaded or converted in either <SI_HOME>/lib or <SI_HOME>/bundles, based on the instructions. jar in runtime Place the non-OSGi JAR you downloaded in <SI_HOME>/jars. jar in samples Place the non-OSGi JAR you downloaded in <SI_HOME>/samples/sample-clients/lib. If you are an extension developer and want to configure manually installable dependencies for a custom extension, see Configuring Extension Dependencies. Installing extensions via the terminal¶ For production setups that don't use WSO2 Integrator, manage Siddhi extensions directly on the SI runtime via the extension-installer script. Navigate to <SI_HOME>/bin to issue these commands. Identifying installation status¶ Viewing the list of installed extensions — view the complete list of Siddhi extensions currently installed in your WSO2 Integrator: SI setup. All listed extensions are completely installed (with their dependencies). On macOS/LinuxOn Windows ./extension-installer.sh list extension-installer.bat list The following is a sample response log for this command. Viewing the installation status of all supported extensions — view the complete list of Siddhi extensions supported for WSO2 Integrator: SI together with the current installation status of each. On macOS/LinuxOn Windows ./extension-installer.sh list --all extension-installer.bat list --all The following is a sample response. Checking the installation status of a specific extension — view the installation status of one extension together with details of any dependencies that need to be manually downloaded. On macOS/LinuxOn Windows ./extension-installer.sh list <EXTENSION_NAME> extension-installer.bat list <EXTENSION_NAME> Info <EXTENSION_NAME> is the value displayed in the name column when you list extensions or check their status. For example, the extension name of the gRPC extension is grpc. For example, to view the installation status of the cdc-oracle extension (which is partially installed by default): On macOS/LinuxOn Windows ./extension-installer.sh list cdc-oracle extension-installer.bat list cdc-oracle Sample response: Installing extensions¶ Installing all extensions required for currently deployed Siddhi applications¶ If the Siddhi applications deployed in your WSO2 Integrator: SI setup use Siddhi extensions that are not currently installed, you can install all those extensions at once: On macOS/LinuxOn Windows ./extension-installer.sh install extension-installer.bat install For example, if a deployed Siddhi application uses the Amazon S3 extension and that extension is not yet installed, the command above prints a message listing the extensions used in your applications but not installed, and prompts you to confirm. If you enter y, installation proceeds and the following message confirms the installation status and prompts you to restart the SI server. Installing a specific extension¶ To install a specific Siddhi extension by name: On macOS/LinuxOn Windows ./extension-installer.sh install <EXTENSION_NAME> extension-installer.bat install <EXTENSION_NAME> For example, to install the grpc Siddhi extension: On macOS/LinuxOn Windows ./extension-installer.sh install grpc extension-installer.bat install grpc The following message confirms the installation status and prompts you to restart the SI server. Uninstalling extensions¶ To uninstall a specific Siddhi extension: On macOS/LinuxOn Windows ./extension-installer.sh uninstall <EXTENSION_NAME> extension-installer.bat uninstall <EXTENSION_NAME> For example, to uninstall the grpc Siddhi extension: On macOS/LinuxOn Windows ./extension-installer.sh uninstall grpc extension-installer.bat uninstall grpc A message lists any other extensions that share dependencies with the one being uninstalled, and prompts you to confirm. If you confirm, the uninstallation proceeds and the following log shows progress before prompting you to restart the SI server.
